(Unit : mm)

MODEL kg 1EA 4EA Ø W F F1 Hole H L O M Y Ø L ACSU-40SF 0.10 15 45 Ø40 17 45×38 34×27 Ø5.2 54 61 18.5 - - - - ACSU-40RF 0.07 45 - ACSU-40SS 0.09 - - - 56 55 18.5 M8 15 ACSU-50SF 0.11 20 60 Ø50 17 45×38 34×27 Ø5.2 65 45 17 - - - - ACSU-50RF 0.08 66 - ACSU-50SS 0.10 - - - 67 60 17 M8 15 ACSU-64SFB 0.43 30 90 Ø64 24 70×58 55×40 Ø8×13L (slot hole) 91 125 34 - - - - ACSU-64SF 0.37 97 29 ACSU-64RF 0.22 70 - ACSU-64SSB 0.39 - - - 93 114 34 M12 25 ACSU-64SS 0.33 86 29 ACSU-64SGRB 0.39 89 114 34 - - Ø11 34 ACSU-64SGR 0.33 86 29 ACSU-76SFB 0.46 35 105 Ø76 24 70×58 55×40 Ø8×13L (slot hole) 105 125 31 - - - - ACSU-76SF 0.41 103 31 ACSU-76RF 0.25 76 - ACSU-76SSB 0.43 - - - 109 114 31 M12 25 ACSU-76SS 0.37 92 31 ACSU-76SGRB 0.43 104 114 31 - - Ø11 34 ACSU-76SGR 0.37 92 31 ACSU-102SFB 0.57 40 120 Ø102 24 70×58 55×40 Ø8×13L (slot hole) 125 125 23 - - - - ACSU-102SF 0.51 111 26.5 ACSU-102RF 0.36 102 - ACSU-102SSB 0.53 - - - 129 114 23 M12 25 ACSU-102SS 0.48 102 26.5 ACSU-102SGRB 0.53 124 114 23 - - Ø11 34 ACSU-102SGR 0.48 102 26.5
